Combination Foot Rail Bracket – Oil Rubbed Bronze – 2″ OD

The favored form among many bracket enthusiasts, combination-style bar rail brackets rest a foot on a floor while an arm mounts to a bar facing. Built from stainless steel and in an Oil Rubbed Bronze finish, this bar bracket, along with 2″ metal tubing and other matching components, makes for a stylish addition to any home or commercial bar.

One reason why this shape of bar foot rest bracket is chosen so often is that, unlike bar mount brackets, you do not need access to the back of the bar to install combination brackets. They mount to the facing of a bar, with one foot of the bracket resting on the floor.

The sleek bronze finish of this combination bracket will precisely match your . To install, use an electric screwdriver to attach the bracket onto the desired location of the tubing with the included set screw, then use the mounting screws to attach the bracket to the face of the bar. Be sure to measure precisely where to place the screws ahead of time.

The bracket sits approximately 6″ off the floor and 6″-7″ away from the facing of the bar. With two contact points, this double-footed bar rail bracket combines a sturdy build and a classy design. For proper support, bar brackets should be placed at each end of the tubing, plus one for every 4-foot increment.

Properly installed bar railing brackets ensure that your foot rail will hold up to the rigors of a whole bunch of feet resting on them. If you’re still unsure of which bracket will fit best in your bar, check out our for more information on each of the options.

• Oil rubbed bronze finish
• For use with 2” Outside Diameter bar rail tubing
• Bracket arm mounts to the face of bar while foot rests on the floor
• Brackets should be used at both ends of rail tubing, plus one at every 4′ increment
• Mounting screws included
• Suitable for indoor use only

• Overall Dimensions: 7.13″H x 7.75″D x 2″W
• Wall to Center of Tubing: 6.125″
• Floor to Center of Tubing: 6″
• Floor to Bottom of Mounting Plate: 5.5″
• Fits 2″ Outside Diameter Tubing
